LS Street Rod Alt/PS Bracket - Camaro F-Body (98-02) / GTO (04-06) - K10208

Narrow Street Rod Alt/PS relocation bracket system for LS engines with Camaro F-Body (1998-02) and GTO (2004-06) crank pulley and water pump spacing.

A perfect LS front serpentine solution for classic street rods and trucks (pre-1948).

This bracket system mounts the front accessories high and narrow for LS swap suitability.
This system can fit inside the hood sides of a 32 Ford!
The system is driven by one main 6-rib serpentine belt.

• Corvette Alternators (1997-2013)
• Truck Alternators (1999-2013)
• Camaro/GTO Alternators (1998-2002)
• Camaro Alternators (2010-15)
• DOES NOT fit Cadillac CTS-V / LSA Alternators

• Pump moved down and in for added frame / steering clearance
• Pump clocked to give ease of access to pressure port

• Kwik Performance pump with 5.5” pulley: 10206-06
• Corvette pump with 6.7” pulley
• Camaro (98-02) pump with 6” pulley*
• *Pulley must be pulled off shaft +/- 1/8” to line up properly
• Camaro (2010-15) pump with 6” pulley*
• *Call for Technical Advice
• GTO (2005/2006)*
• *Call for Technical Advice
• *2004 GTO pump does not work

Mounts Factory OEM PS remote reservoir conveniently above the PS pump (optional)

Exceeds OEM Corvette level of PS Pump belt wrap.
