Kwik Performance Inc.  |  SKU: K10581

LT Truck (2020+) AC/PS Bracket - K10581

$625.00 USD
Shipping calculated at checkout.

Description

AC and Power Steering bracket system for Gen 5 LT truck engines with centered water pump.

Add hydraulic power steering (pump included) to your LT engine swap.

Relocates Sanden AC compressor and adds Type 2 power steering to the driver’s side of the engine.

Requires use of GM water pump used on 2019 and later truck engines, L82, L84, L87 and L8T.

Note:
    The water pump housing must have a machined surface on the passenger’s side of the casting to accept an L8T belt tensioner. The following casting numbers can be found on the face of the water pump housing: 12383468, 12687631, 12707680, 12708893.

Some 1500 pickups with 5.3L and 6.2L engines (L82 L84 and L87) have the centered water pump but did not use a spring-loaded tensioner and therefore the casting was not machined. For example, some, but not all of casting number 12383468 are machined.

All 6.6L (L8T) engines use a spring-loaded tensioner and will have the correct water pump, casting number 12707680.

Engines from 2014-18 (L83 and L86) have the water pump offset to the driver’s side. However, the centered water pump mentioned above will bolt up to these earlier engines. If you want to keep the offset water pump, check out our LT Truck (14-19) AC-Alt/PS Bracket: (Kwik Performance PN K10438).

    What's Included / Other requirements

    What's included:

    Bracket made of 6061-T6 aircraft grade aluminum (brushed satin finish)

    All necessary spacers and zinc coated fasteners

    Power Steering Pump

    Power Steering Reservoir

    Idler Pulleys

    What else is required to complete the installation:

    GM LT Gen 5 engine with truck (2014+) harmonic balancer

    LT Truck alternator (uses OEM bracket and location)

    Gen 5 truck water pump with centered pulley (see above)

    L8T (6.6L) belt tensioner and idler pulley assembly

    Six-rib belt (Gates K061005)

    Complete Gates belt chart available here. GATES BELT CHART

    Alternator rating and PS pulley diameters can change suggested lengths.

    Always check tensioner marks for correct fitment.

    Sanden SD709 AC compressor (also known as SD7H15)

    We recommend the 709 over the 508 compressor for smoother operation and slightly more cooling capacity.

    View the SD7H15 AC compressor: (Kwik Performance PN 10300-01).

    Power Steering hose kit

    View our Hose Kit: (Kwik Performance PN K10548).

    Installation Instructions

    LT Truck (6.6L L8T) AC/PS Instructions

    Gates Belt Chart (Part number and length)

    FAQs

    Why relocate the AC compressor for an LT swap?

    GM made a fantastic engine with the LT design, but they didn’t always put the accessories in the best location for us engine-swapping hotrodders.
    By locating the AC compressor just outside the driver side cylinder head you solve the possible frame clearance issues with chassis such as:







    Why use a genuine Sanden AC compressor?

    Many OEM AC compressors are a “variable displacement” design and don’t work well with older OEM or aftermarket AC systems

    The OEM compressors have a 4-groove pulley instead of the 6-groove needed when moving the compressor to a higher location

    Sanden is the aftermarket standard for AC compressors, recommended by most major AC manufacturers

    Why you should use a Kwik Performance product:

    Properly engineered using OEM reference drawings

    Computer tested with FEA (finite element analysis) software

    Field tested on shop test engines and in real-world test vehicles

    Backed by a no-hassle warranty and return policy

    Tech support before, during and after the sale
