BBC Serpentine Package, AC-Alt/PS - P-series pump (Sanden 508/709) - K10654

What's included:

Brackets made of 6061-T6 aircraft grade aluminum (brushed satin finish)

All necessary spacers and zinc coated fasteners

Automatic spring-style tensioner

Idler Pulleys

Water Pump pulley

SBC crank pulley with BBC (1966-93) crank pulley adapter

*If your BBC engine is a (1994-2000):

Call us and we will make sure you get the correct adapter

What else is required to complete the installation:

GM BBC engine (1966-1993) -or (1994-2000)*

366, 396, 402, 427, 454, 502, 572

Power Steering Pump, Truck (P-series) 1975-2013. The pump must have a smooth shaft (no keyway).

Consider the all new Edelmann 6023R P-series pump or for Hydroboost, the Edelmann 6091R P-series pump.

P-series pump serpentine pulley, 3P-25160.

Six-rib belt, See our included installation instructions for suggested lengths and Gates part numbers. Alternator rating and PS pulley
diameters can change suggested lengths. Always check tensioner marks for
correct fitment.

Sanden 508 or 709 AC compressor. We recommend the 709 over the 508 compressor for smoother operation and slightly more cooling capacity (Kwik Performance PN 10300-01).

CS130 (serpentine) Alternator (GM Truck 1990-1995)

Consider our PowerMaster 1-wire alternator: (Kwik Performance PN 47861).

A reverse rotation water pump off of a
1988-1999 454 engine. Consider our Gates replacement Water Pump: (Kwik Performance
PN 44030).

This is considered a "long"
pump and is 7 5/16" from block to fan mounting surface.

Download Installation Instructions (Adobe pdf File) for Tensioner bracket

Download Installation Instructions (Adobe pdf File) for Tensioner bracket

Big Block Spotters Guide (Adobe pdf File)

Gates Belt Chart (Part number and length)

Why you should use a Kwik Performance product:

Properly engineered using OEM reference drawings

Computer tested with FEA (finite element analysis) software

Field tested on shop test engines and in real-world test vehicles

Backed by a no-hassle warranty and return policy

Tech support before, during and after the sale

Why use a genuine Sanden AC compressor?

Many OEM AC compressors are a “variable displacement” design and don’t work well with older OEM or aftermarket AC systems

The OEM compressors have a 4-groove pulley instead of the 6-groove needed when moving the compressor to a higher
location

Sanden is the aftermarket standard for AC compressors, recommended by most major AC manufacturers
